| Product Attribute | Attribute Value |
|---|---|
| Current, Supply | 0.12 A |
| Ethernet Transfer Rate | 100 Mbit/s |
| Mounting Type | Wall/DIN Rail |
| Number of Ports | 2 Port |
| Operating Temperature | –10 to 60 °C |
| Port, Type | RJ45 |
| Power Loss | 3 W |
| Primary Type | Ethernet Switch |
| Protection Class | IP30 |
| Protocol Type | 100 Mbit/s |
| Series | |
| Special Features | Automatic Data Transmission Rate Detection ; Auto-Sensing ; Auto-Crossover Function |
| Supply Voltage | 24 VDC |
| Type | Unmanaged Switch |
| UPC Code | 662643297102 |
Overview
SIEMENS SCALANCE Series – Unmanaged Ethernet Switch
The unmanaged Industrial Ethernet switches of the SCALANCE XB-000/XB-000G line allow cost-effective solutions for setting up small star or line topologies with switching functionality in machinery or plant components. The enclosure is designed for space-saving installation in a control cabinet on a standard rail. Wall mounting is also possible.
The SCALANCE XB-000/XB-000G Industrial Ethernet switches are optimized for mounting on a standard rail. They have:
– A 3-pin terminal block for connecting the power supply (1 x 24 V DC) and functional ground.
– An LED to display status information (Power)
– LEDs for indicating the status information (link status and bdata exchange) per port
Features:
The following port types are available:
